JL Audio HD750/1 Class D Monoblock Full-Range Car Amplifier 750W RMS
JL Audio HD750/1 Monoblock Class D, HD Series Small Profile Car Amplifier with R.I.P.S. Technology JL Audio HD Series Monoblock Class D, Small Profile Car Amplifier with R.I.P.S. Technology RMS Power Rating: 1.5-4 ohms: 750 watts x 1 chan. Max power output: 750 watts x 1 chan. MOSFET power supply Remote bass level input (HD-RLC required and sold separately) LED power indicators Single channel operation Preamp RCA outputs Single Cycle Controlâ„¢ Heavy duty aluminum alloy heatsink for heat dissipation RCA level inputs Screw terminals Variable high-pass filter (50-500 Hz, 24 dB/octave) Variable low-pass filter (50-500 Hz, 24 dB/octave) Frequency response: 6-30,000 Hz Dimensions: 10-13/16"L x 8-1/4"W x 1-15/16"H
JL Audio HD750 1 Class D Monoblock Full-Range Car Amplifier 750W RMS Features
- Bass EQ: Remote Level Control (with optional HD-RLC)
- Preamp Output: 2-channel, buffered pass-through type
- On-board Crossover: State-variable, 12 dB/octave Butterworth or 24 dB/octave Linkwitz-Riley, Low-Pass or High-Pass
- Differential-Balanced Input Topology: 1 pair of inputs
